1、 Performance Overview

Drive intrinsically safe low-power equipment in hazardous areas by controlling the output through dry contacts, collector open circuit signals, or logic level signals. Intrinsic safety equipment such as solenoid valves, sound and light alarms, etc.

Three party isolation of input, output, and power supply terminals.

2、 Technical parameters

Explosion proof grade: [Exia] IIC

Safe zone allows input signal: dry contact collector open circuit signal

Logic level: When 5V~30V, it indicates "on" and supplies power to the on-site equipment

When 0V~1V, it means "off" and stops supplying power to the on-site equipment

Output signal to danger zone: digital output drives solenoid valve or alarm

Large output voltage: 22V Small output voltage: 12V

Current limit: 45mA

Dielectric strength: ≥ 2500V AC (between input/output/power supply, leakage current 1mA, test time 1min)

Insulation resistance: ≥ 100M Ω (between input/output/power supply)

Electromagnetic compatibility: EMC complies with IEC61000-4

Certification parameters of the National Quality Supervision and Inspection Center for Instrumentation and Electrical Products (CQST): Between terminals 9 and 10: Um=250V AC/DC

Uo=25.2V，Io=109mA，Po=687mW

ⅡC           ⅡB        ⅡA

Co        0.074μF       0.57μF    2.03μF

Lo        2.1mH         6.3mH     16.8mH

Power supply: DC 18-32V (typical value 24V DC)

Power consumption: 1.2W

Panel indicator light

PWR： Power indicator light (green). The instrument stays on normally during normal operation;

CH： Output signal status indicator light (red). It lights up when outputting a signal.

Usage environment

Working environment temperature: - 20℃～+60℃

Allowable relative humidity at work: 10% RH to 90% RH (40 ℃)

Allowable atmospheric pressure during work: 80kPa~106kPa

Allowable ambient temperature during storage and transportation: - 40℃～+80℃
